Flash Redmi note 5 pro in EDL mode without unlocking boot loader

Flash Official Firmware on Redmi Note 5 Pro MIUI9 [Unbrick Redmi Note 5 Pro]
Xiaomi has recently released Android Nooggate Phone - Redmi Note 5 Pro MIUI9. This is very fast but if you are trying to download Official Stock Rome firmware for Xiaomi Redmi Note 5 Pro, please see the download section below and download the official Nougat firmware for Redmi Note 5 Pro Mobile.

If your Redmi Note 5 Pro resolves the problem related to any software or is running, then flash the official firmware on Radmi Note 5 Pro without dead risk. Flashing is very useful for unbricking your own Redmi Note 5 Pro MIUI9 without the help of a customer service or repair center. Here in this flashing guide will be shown how easy it is to install stock ROM on Redmi Note 5 Pro using mi flash tool.

Redmi Note 5 Pro Specification

Redmi Note 5 Pro was released in February 2018. Redmi Note 5 Pro is dual-SIM supported, 5.99-inch Android Nougat 7.1.2 smartphone features a fingerprint sensor. Qualcomm SDM 636 Snapdragon 636 Chipset, Octa-Core 1.8 GHz Krio 260 CPU, 64GB ROM and 4/6GB Ram Radmi Note 5 Pro are the other smart features of the latest Xiaomi on the phone.

Now come to the point and see how to use the Mi Flash tool on Redmi Note 5 Pro Recovery ROM or Fastboot Rom?

In this post we assume that you can access your device and want to upgrade the firmware on Redmi Note 5 Pro, or want to upgrade or downgrade or fix issues related to software such as boot logos, Which have been stuck on the mi logo etc.






Download Redmi Note 5 Pro Firmware, Drivers & Tools

[Direct Link] Redmi Note 5 Pro Official Firmware – Link

Driver

Redmi Note 5 Pro Flash Tool – Mi Flash Tool

How to Flash Redmi note 5 pro in EDL mode without unlocking boot loader

1. Turn off the phone and remove the SIM card tray. Now use tools/nail to remove back panel. Start from the bottom of the phone. Do not use too much force.

2. Remove 2 screws as shown below. To see Test Point on the phone.

3. Disconnect the battery connector carefully from the main board as shown in the picture below. Now the time of test point. The test point area can be covered by tape. You need to peel the tape.

4. Now you need short / wire to short and connect to EDL mode by entering the entry points. Minimize test points with a chooser or wire, and now connect the USB to the PC. When PC detects new hardware, remove tweezers/wire from Test Points.

5. Open the Device Manager on your PC. If you see QHUSB_BULK in Device Manager, right-click and select the update driver.

6. Browse My Computer for Browse Driver Software And select the Qualcomm HS-USB QDLoader 9008 drivers you downloaded above. Choose to install this driver software anyway.

7. The driver will be installed successfully and you can add Qualcomm HS-USB in the port. And you are ready to flash the Fastboot ROM on your phone.

8. Go to your desktop and install Mi Flash Tool and you will see the Mi Flash app on your desktop.

9. Now unzip the Fastboot ROM folder on your desktop and you will see some files and picture folders in the Fastboot ROM folder.

10. Now run the Mi Flash Tool app on your PC.

11. Ensure your phone is connected and the phone is in EDL mode

12. Now click on the refresh button in the Mi Flash tool and you will see your phone connected to the app.

13. Now go to the Fastboot ROM folder and copy the folder's URL.

14. Now paste the URL in the address bar of the Mi Flash Tool. See the image below.

15. Now in Mi Flash Tool. Click on "Clean All" option form bottom right corner. If you want to lock the bootloader again, select "Clear All and Lock". But we recommend you choose the Clean All option, this will not lock your phone bootloader.

16. Now you are ready to go. Press the flash button and the flashing process will start on your phone and it will take 5 to 6 minutes to complete the process.

17. Once the flashing process is complete, you will see the success message on Mi Flash Tool. And your phone will reboot automatically.

Now you successfully flash the Fastboot ROM on your Redmi Note 5 Pro. Remove the cable and connect the battery connector to the phone and turn it on.

Gather the phone again in power off mode. The device will start, wait until it completes, it can take 10-20 minutes. Hope you guys will like this guide, if you have any questions or are experiencing some issues with this guide then leave comments below, we will help you fix it.
